Nova Star TB 40 Led Controller

Name: Nova Star TB 40 Led Controller
Brand: HINDUSTAN LED BOARDS
Price: 17000.0 INR
Availability: InStock

Price 17000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece Piece

Nova Star TB 40 Led Controller Specification

Input Voltage
DC 5V

Display Function
Image/Video/Text Display

Application
Advertising, Stage Rental, Fixed LED Displays

View Angle
Depends on LED Display Specification

LED Type
Compatible with mainstream LED display modules

Screen Dimension
Max 4096 pixels (width) 4096 pixels (height)

Usage
LED Display Screen Control

Tube Chip Color
Full Color RGB

Size
270 mm 166 mm 42.5 mm

Protection Level
Standard casing (Indoor Use, IP20)

Power Consumption
~10W (controller only)

Working Temperature
-20C to 60C

Control Mode
Ethernet, USB, and Wi-Fi control options

Pixels
Supports up to 650,000 pixels per controller

Brightness
Depends on LED Display Panel

Gray Scale
Up to 65536 level gray scale

Video Signal Input
HDMI, DVI, USB, Wi-Fi

Software Compatibility
NovaLCT, V-Can cloud platform

Refresh Rate
Supports up to 1920~3840Hz depending on module

Storage Capacity
8GB Onboard Storage

Remote Control
Supports remote configuration and monitoring

Mounting Type
Rack Mount / Desktop

Output Interface
4 x Ethernet outputs

Weight
Approximately 1.5 kg

Audio Output
3.5mm Audio Port Supported

Synchronous/Asynchronous Control
Supports both

Product Model
Nova Star TB 40

Nova Star TB 40 Led Controller Trade Information

Minimum Order Quantity
1 Piece Piece

Delivery Time
5-7 Days

Nova Star TB 40 Led Controller About

The Novastar TB40 LED Display Controller TB40(Upgrade Version of TB4) acts as an upgraded playback solution offering HDMI input/output and robust performance for commercial digital signage.

Versatile Control and Connectivity

The Nova Star TB 40 offers flexible control modes with Ethernet, USB, and Wi-Fi, making it adaptable for varying display environments. It can be operated via desktop or rack mounting, supporting seamless integration into existing audio-visual setups. The controller features remote configuration and monitoring, allowing users to manage display content easily, whether onsite or remotely via the V-Can platform.

High Performance for Professional Displays

Equipped with up to 8GB of onboard storage and support for up to 650,000 pixels per controller, the TB 40 guarantees smooth playback of images, videos, and text. The controller provides exceptional grayscale performance up to 65536 levels and a high refresh rate of up to 3840Hz (dependent on your LED module), delivering clear, flicker-free visuals suited for demanding indoor applications.

FAQ's of Nova Star TB 40 Led Controller:

Q: How do I configure the Nova Star TB 40 LED Controller for my display setup?

A: You can configure the Nova Star TB 40 using either the NovaLCT software or via the V-Can cloud platform. This allows for both local and remote setup, enabling easy input management, screen mapping, and settings adjustment through Ethernet, USB, or Wi-Fi connections.

Q: What is the process for connecting video and audio signals to the TB 40?

A: Simply connect your video sources via HDMI, DVI, or USB input ports. For audio, the TB 40 offers a 3.5mm port, allowing you to incorporate external sound to your displays. Network output is handled through four Ethernet ports to link with your LED display panels.

Q: When should I use the synchronous versus asynchronous control mode?

A: Synchronous mode is ideal when you need real-time content display, such as for live events. Asynchronous mode is best for scheduled content playback, commonly used in fixed installations or advertising where continuous playback is needed without connection to a live source.

Q: Where can I use the Nova Star TB 40 LED Controller?

A: This controller is built for indoor environments (IP20 protection) and is suitable for applications like advertising screens, stage rentals, and fixed LED displays requiring high resolution and smooth visual performance.

Q: What are the benefits of remote configuration and monitoring with the TB 40?

A: Remote configuration allows users to adjust content, troubleshoot, and monitor performance from anywhere, saving time and reducing the need for onsite staff. This feature is particularly valuable for distributed display networks or unattended installations.

Q: How does the TB 40 handle high pixel and refresh rate demands?

A: The controller supports up to 4096x4096 pixels in dimension and up to 650,000 pixels per controller. Its advanced processing capabilities allow refresh rates up to 3840Hz (dependent on your display module), ensuring vivid, seamless animation and video playback.
